Laguna Tools MDCCF22201 C|Flux:2 2HP 220V Cyclone Dust Collector with Canister Filter

PRODUCT DETAILS

Click an item to expand and learn more

• Overview
  For the popular C|Flux cyclone dust collectors, we’ve kept the user-friendly aspects of the previous generation while adding smart new features to improve the user experience. Among the upgrades is a dual-paddle filter cleaning design, and a max level indicator to increase filter longevity. The iconic octagonal drum grows to an impressive 46-gallon capacity on the C|Flux 2 and 3 models, and the newly redesigned 3-piece drum construction requires far fewer joints and fasteners cutting assembly time, while the locking casters provide additional stability.

  Features:

  • 2 HP Motor
  • 1740 CFM Maximum Air Flow
  • 46 Gallon Octagon Drum

  Additional Details:

  • Motor Specs: 2HP
  • Electrical Specs: 220V/ 60Hz / 1PH / 3450 RPM
  • Running AMP: (6″ inlet) 14A at 220V
  • Maximum Air Volume: 1740 CFM (Cubic Feet Per Minute)
  • Shop Setting Air Flow*: 1166 CFM
  • Max Static Pressure: 9.3″
  • Fan Size: 14.5″
  • Inlet: 6″ (8″ x 6″) Or (8″ x 4″ x 2 Ports)
  • Remote Control: High Frequency
  • Collection Capacity: 46 Gallon Octagon Drum
  • Decibel Reading: 88 dB (@9.8ft)
  • Assembled Dimensions (L x W x H): 48″ x 28″ x 87″
  • Packing Size (L x W x H): 50″ x 31.5″ x 50.6″ (127 x 80 x 128.5 cm)
  • Machine Weight: 301 lbs. (140 kg)
  • Shipping Weight: 377 lbs. (171 kg)
  • Cord: approx 8ft cord
  • Filtering Area: 102 sq/ft (9.5 sq/m)
  • Cartridge Filter: 1 Micron, 15.74″ x 35.43″ (40 x 90 cm) x 1pc

  * Shop Setting Air Flow measured with hoses connected to inlet.

  Uses:

  • Dust collection from table saws
  • Removing sawdust from band saws
  • Extracting particles during sanding operations
  • Keeping work area clean during routing tasks
  • Dust control for jointers and planers
  • Enhancing air quality in the workshop
  • Supporting dust-free drilling operations
  • Collecting debris from wood lathes
  • Maintaining cleanliness during wood carving
  • Assisting in general shop cleanup

  Read More

• Reviews
• Questions and Answers
• Manuals

  Download Manual Instructions PDF

  Download Parts Manual PDF

• FAQ

  What size is the inlet?

  The inlet port size is 8”. It comes with a splitter that fits over the 8” inlet. The splitter has two 4” inlets so that you can connect multiple hoses to the machine. We recommend installing blast gates on each side so that you can control which machine you are collecting from when multiple machines are connected.

  Will I need to assemble the dust collector?

  Yes. The C|Flux dust collectors ship disassembled to avoid damage during shipping and requires assembly prior to use.

  Can I reuse the collection bags?

  Yes. You can empty and reuse the dust collection bags if desired. Replacement bags are also available. These are sold in a package of 5 bags. The fine dust bag at the bottom of the filter can also be reused.

  Why are there 2 numbers listed for CFM?

  The “Inlet CFM” is the maximum CFM the C|Flux dust collector achieves at the inlet port. The “Shop Setting CFM” number provides a “real world” measurement with dust collection hose connection to the machine and measurements taken downstream.

  How fine is the filter?

  The C|Flux filter cartridge is a 1 micron filter. The filter cartridge is easy to clean using the included filter cleaning handle. A few quick turns of the handle cleans dust out of the filter pleats so that it is ready for the next use.

  Will this keep from having dust in the shop?

  The C|Flux dust collector is excellent at collecting dust, chips, and shavings from the source (bandsaw, tablesaw, planer, etc.). This helps keep the dust away from the moving parts of the machines to keep it from becoming airborne. We recommend a dual approach for shops:

  1. Removing dust from the source with a quality dust collector.

  2. Filtering ambient shop air, particularly when sanding or other operations that produce fine dust, with an Air Filtration System. This two-step collection provides the best air quality for your shop.

  Does the C|Flux come with a remote control?

  Yes, the C|Flux comes with a remote control. Additional remotes can be purchased and paired with the C|Flux machine. Up to 5 remotes can be paired.

  Can I connect this to ducting for several machines?

  The C|Flux dust collector is designed for direct hose connections to individual machines, although many users have small ducted systems for a few machines. We recommend dust collectors with higher CFM ratings like the C|Flux:3 and P|Flux:3 series machines for ducted systems. If you choose to connect multiple machines with ducting, you will want to remove the splitter to connect a 6” main trunk line with 4” drops to each machine using blast gates to turn off collection to machines not in use to maximize CFM to the machine currently in use.

  Can I collect materials other than sawdust with this machine?

  Our dust collectors are specifically designed and tested for woodworking dust, chips, and shavings and are designed to collect from woodworking machines. We have customers who use our dust collectors for many other applications such as plastics, paper, grinding dust, powder, and a wide range of other materials from various sources or machines. While our dust collectors may work well for these other applications, we do not have any testing data or connection information for these other uses. You will need to decide which unit would be best for your needs based on the CFM and how you intend to connect to your equipment.

  Can I use other remote controls like iVac?

  No. The C|Flux machines use magnetic safety switches which are not suitable for aftermarket systems like the iVac system. Use of these types of systems will require bypassing the factory switches.

  What machines does this work best with?

  The C|Flux dust collector is designed for single-machine operation. It works well with Tablesaws, Bandsaws, Jointers, Planers, Sanders, Router Tables, and more.

  What size hose should I use for the C|Flux dust collector?

  The inlet on the C|Flux: 2 is an 8” inlet. It is supplied with a 2-way splitter that fits onto the 8” inlet. The splitter has two 4” inlet ports. We recommend using a 4” diameter dust collection hose with this machine. Should you need to connect to machines with smaller outlets like miter saws or similar portable machines, we recommend stepping the 4” hose down with a reducer near the machine being connected to. Users may need to provide “bleed air” when stepping down to smaller sizes. This is accomplished by installing another inlet on a Y fitting that can be opened to introduce additional ambient air into the air-stream when collecting from smaller outlets. This additional air helps to keep up the velocity in the 4” hose and keeps the impeller from starving for airflow when connected to small ports.

  What is the warranty?

  New woodworking machines sold by Laguna Tools carry a two-year warranty. Machines sold through dealers must be registered with Laguna Tools within 30 days of purchase to be covered by this warranty. Laguna Tools guarantees all new machines sold to be free of manufacturers’ defective workmanship, parts and materials.

  Where is Laguna made?

  Laguna Classic Series machines are designed in California at our Huntington Beach facility and are manufactured and shipped globally. The Cflux dust collector is manufactured at an ISO-9001 certified facility in Taiwan.

  Is the C|Flux dust collector certified?

  Yes, the C|Flux dust collector is CSA inspected and certified. The CSA certification means it has been tested against applicable North American standards requirements and is widely accepted by many government and code officials, regulatory and regulation bodies, leading retailers, and Authorities Having Jurisdiction (AHJ). The CSA mark demonstrates that a product has been rigorously tested to applicable standards. These include standards written or administered by the American National Standards Institute (ANSI), Underwriters Laboratories (UL), CSA Group (CSA), NSF International (NSF), and other North American and global organizations

  Can the remotes be used through walls?

  The remotes are RF (radio frequency) rather than the IR (infrared) type used by other manufacturers. The RF remote controls do not require line-of-sight like IR remotes. This allows them to be used through many walls. An additional benefit is that they do not affect fluorescent shop lighting.

  Can I change the motor from 2 to 3 HP?

  Changing from 2 HP to 3 HP would not have any effect on CFM. Our 3 HP models use more powerful motors to spin larger impellers to increase CFM. The larger motors also use larger overloads to match the additional draw from the larger motor.
