The 1HP Dust Collector is designed to eliminate cleanup after using your wood sanding machine. It has a TEFC induction motor for long-lasting, smooth performance along with a reversible motor assembly to complement the machine you are working with. The unit includes a 1HP, 8 amp, 3400 RPM service for up to 680 CFM.
Features
- 1 HP TEFC induction motor for long-lasting, smooth performance
- Reversible motor mounting capability to better direct air flow (suction up/down)
- Finned aluminum motor housing keeps motor running cool during long periods of use
- Curved 10.5†steel impeller produces maximum air velocity for efficient dust collection
- Sturdy steel base with four easy-gliding wheels for moving from machine to machine or for storing out of the way
- Maximum 680 CFM
- 1 micron top and plastic bottom collection bags provide large dust collection capability
The 1 micron bag can collect up to 99% of particles as small as 5 microns and 90% of particles as small as 1 micron in size. In other words, you’ll have a clean shop.
Specifications
- Style (Type): Bag – 1 Micron (Top)
- Air Flow: 680 CFM
- Static Pressure: 7.6″ of Water
- Bag Diameter (in.): 14″
- Top Filter Bag Length: 1 Micron Cloth – 32″
- Bottom Collection Bag Length: Plastic (3 Included) – 38″
- Space Occupied (L x W x H): 30 x 15″ x 73″
- Packing Size: 31″ x 17″ x 16″
- Gross/Net Weight: 84 lbs/79 lbs
- Impeller: 10.5″ Steel
- 1-Hose Connection Diameter (in.): 4″
- Motor Power (HP): 1 TEFC 3400 RPM
- Motor Phase (PH): 1
- Motor Voltage (V): 115/230
- Prewired Voltage (V): 115
- Motor Amps: 8/4
- CSA Approved: Yes
- Warranty: 3 Years
- Decibels Output: 75dB
- Sanding Capacity:
- Maximum Width: 13″
- Minimum Length: 9″
- Maximum Thickness: 4″, Varies With Drum/Brush Style
- Minimum Thickness: 1/32″
- Dimensions (L x w x H): 35″ x 42″ x 44″
- Drum: 6-8″ Typical Diameter
- Speed: Ranged Variable RPM, 400-1200
- Dust Hood: 1-4″ Port, Hinged At Back, 600 CFM Minimum Recommended
- Conveyor Motor: 43 in-lb Torque, Ranged Variable, 0-10 FPM
- Drive Motor (TEFC): 1¾ HP
- Power Requirements: 110 Volt, 20 Amp Service
- Shipping Weight: 84lbs
- Shipping Dimensions (L x W x H): 32in x 18in x 16in
Uses:
- Collecting sawdust from table saws
- Extracting particles from sanding operations
- Keeping work areas clean around wood lathes
- Removing dust from drill presses
- Enhancing air quality during routing tasks
- Maintaining cleanliness near jointers
- Supporting dust-free environment around planers
- Capturing debris from miter saws
- Minimizing dust in wood carving areas
- Reducing airborne particles near band saws
