Woodpeckers Cam-A-Line Dowel Guide combines variable spacing, precision-engraved centerlines, a robust fence and a versatile stop system to give you the most complete dowelling jig on the market. Unlike other dowelling jigs, you're not limited to a certain dimension between pins and you don't have to try to remember which bushings you used. Just adjust the spacing to your material and go. You have your choice of 4 different guide bushing sizes in both inch and metric. You can get Cam-A-Line with just one size, or get the Deluxe set, which includes all 4 sizes, extensions for the stop and a wall-mountable Rack-It to keep everything right in plain sight and ready to go to work.
Butt Joints, T-Joints, Miter Joints and Edge Joints on Any Stock Thickness or Size!
Cam-A-Line uses a sliding cam system to maintain even spacing between 3 drill guide bushings. You can space the bushings as close as 3/4" (20 mm) center-to-center or spread them out up to 1-3/4" (44 mm) center-to-center. This spacing range lets you have an evenly spaced three-dowel array on a workpiece from 2-1/4" wide up to 5-1/2" wide. You can go narrower than 2-1/4" by using only 2 of the guide bushings and you can go wider than 5-1/2" by using groups of pins.
The easiest way to use Cam-A-Line utilizes the engraved centerlines. Just clamp your two boards together exactly where you want them. Strike a line across the joint. Align Cam-A-Line's engraved centerline with the marks on each piece and drill your joint. The holes will line up perfectly and create a joint that rivals loose tenon or mortise and tenon joints for strength and durability. You can use the same process for miter joints, too.
When you have stacks of similar joints to make, the stop system speeds things up, compared to using a centerline. Once your stop is set, it provides a quick physical reference to locate your work, eliminating aligning the jig to a pencil mark. You can quickly re-index the stop on the other end of the jig to drill the mirror image on your joining piece.
Using dowels in edge-glued panels can save hours of hand planing and sanding. The dowels keep the top surface of your panel flat, even when the sections have a little bit of twist or bow. The extension rods for the stop system let you set the spacing between dowel pins wherever you want it.
Like all Woodpeckers products, the Cam-A-Line Dowel Guide is precisely machined and carefully inspected in Strongsville, Ohio, facility just south of Cleveland.
Uses:
- Aligning dowels for precise joining of wood pieces
- Ensuring accurate dowel placement in shelving and cabinet construction
- Creating consistent dowel holes for repeatable results in multiple workpieces
- Assisting in the construction of wooden frames and panels
- Facilitating the assembly of complex wood furniture such as chairs and tables
- Enhancing the accuracy of dowel joints in woodworking projects
- Supporting the alignment of components in craft projects and small wooden items
- Improving the structural integrity of DIY woodworking projects through precise dowel placement
- Aiding in the repair of wooden items by ensuring dowels fit perfectly
- Streamlining the process of building custom wooden storage solutions like bookcases and wardrobes
