Powermatic PM9-PM25350RKT-4 ArmorGlide PM2000T 10 Inch Table Saw, 50 Inch Rip, Router Lift, 5HP, 3PH, 460V

PRODUCT DETAILS

Click an item to expand and learn more

• Overview
  Now featuring ArmorGlide Technology that is low-friction and rust-resistant, the award-winning PM2000B table saw sets a new standard for innovation with an array of patented features and massive body design. The ArmorGlide coated cast iron tables are oversized, and the newly designed arbor lock lever is accessible from above the table top to eliminate the need for dual arbor wrenches. The quick-release riving knife design helps reduce the chance of kickback. The blade tilt scale features an integrated digital readout as well as adjustable angle indicators for repetitive bevel cuts.The newly designed integrated retractable hydraulic caster system lifts your table saw much higher than the previous model to assist when moving over thresholds. A wide stance, heavy-duty box trunnion and concave teeth on the trunnion gears promote easier raising and tilting of saw blade. Poly-V drive belt system results in quieter, more efficient power transfer from the motor to the arbor with virtually no vibration and less heat build-up. Improved built-in dust collection port with convenient access to the inside of the saw cabinet for simple clean-up. The saw has a proprietary safety switch with magnetic interlock and the stop button can be knee activated.

  • ArmorGlide Technology gives you a low-friction, industrial-grade coating on the work surface that is rust resistant, requires less maintenance, and gives you more control.
  • Miter guage is built with robust materials with many positive stops for the most commonly used angles.
  • Adjustable angle indicators on the blade bevel scale for repeatable bevel cuts
  • Arbor lock for quick and easy blade changes
  • Integrated digital read out for precise bevel cuts
  • Integrated dust collection
  • Integrated hydraulic castor system for ease of movement around the shop
  • Matching beveled edge between table and extension wings
  • One-piece cast iron box trunnion provides the strongest stability of any Powermatic table saw
  • Precision-ground, high luster cast iron tabletops with front and rear edge bevel
  • Quick release riving knife lever for hassle free riving knife changes

  Dimensions

  • Blade Diameter (in.): 10 in
  • Product Depth (in.): 84.75 in
  • Product Height (in.): 40.375 in
  • Product Width (in.): 39.125 in
  • Work Table Height From Floor (in.): 35 in
  • Work Table Length (in.): 30.5 in
  • Work Table Surface (in.): 30.5 in x 22 in
  • Work Table Width (in.): 22 in

  Details

  • Amperage (A): 6.5 A
  • Bench & Stationary Tool Type: Table Saw
  • Blade Location: Centered
  • Color Family: Gold
  • Condition: New
  • Construction Material: Cast Iron
  • Cord Length (ft.): 0 ft
  • Cordless/Corded: Corded
  • Cuts Through: Nylon, PVC, Plastic, Wood
  • Depth Control: Yes
  • Dust Collection Method: 4 in. Dust Port
  • Horsepower (HP): 5 hp
  • Included Accessories: Anti-Kickback Prawl, Blade Guard System, Blade(s), Miter Fence, Rip Fence, Side Extension
  • Maximum Cut Depth at 45 Degrees (in.): 2.125 in
  • Maximum Cut Depth at 90 Degrees (in.): 3.125 in
  • Maximum Speed (RPM): 4500 RPM
  • Maximum Table Tilt - Left (degrees): 0 °
  • Maximum Table Tilt - Right (degrees): 0 °
  • Portability: Floor
  • Power Tool Features: Blade Guard System, Depth Adjustment, Heavy Duty, Keyed Blade Change
  • Product Weight (lb.): 737 lb
  • Returnable: 90-Day
  • Rip Capacity - Left (in.): 13.5 in
  • Rip Capacity - Right (in.): 50 in

  Uses:

  • Custom furniture creation, allowing for precise cuts and detailed craftsmanship
  • Cabinetry and woodworking, enabling the production of intricate designs and sturdy builds
  • Home renovation projects, such as creating custom shelving or unique wood features
  • Construction of wooden toys or puzzles, providing the ability to work with fine details
  • Crafting wooden signs or art pieces, offering precision for creative designs
  • Building and designing wooden frames for paintings or photographs
  • Fabrication of wooden panels and partitions for interior design
  • Creation of prototypes for woodworking projects or new product designs
  • Educational purposes in workshops or vocational training centers, teaching students about woodcraft and machinery use
  • Use in theatrical set design, allowing for quick and accurate construction of stage elements
