Compact Zyklop ratchet with bit magazine for the pocket. Magnetic direct mounting for ¼" bits and 3/8" sockets. Rapid tool change thanks to the non-locking mounting. As the head is lockable at 0°, 15° and 90°, the tool can be used as a ratchet and as a ratchet screwdriver. The fine toothing with 72 teeth allows for a low return angle of 5°. Wide range of applications thanks to 12 bits integrated in the handle. The robust ratchet mechanism allows for ample torque. Perfect combination of a Zyklop ratchet with a 12-piece screwdriver set. The 75 mm long universal holder for 1/4" bits can be used as an extension. Including sockets in the commonest dimensions. One robust textile holster 9468 to be attached to the belt and docked onto the Wera 2go system.
- Compact Zyklop ratchet with integrated bit magazine
- The magnetic direct mounting simultaneously turns the 3/8" ratchet into a bit ratchet screwdriver with 1/4" bit mounting
- Freely pivoting ratchet head with 5 predefined locking positions
- Fine tooth reversible ratchet (72 teeth) for a low return angle of only 5°
- Captive and freely swivelling bit magazine for easy removal and secure storage of the bits
- Universal holder with stainless steel sleeve and strong permanent magnet, can be used as extension
- Robust textile holster to be attached to the belt and docked onto the Wera 2go system
Uses:
- Assembling furniture and fixtures at home or in office spaces.
- Performing routine maintenance on bicycles, motorcycles, and other small engines.
- Conducting repairs and installations in tight spaces where traditional tools might not fit.
- Ideal for automotive work, especially for tasks involving nuts and bolts in confined areas.
- Useful for electronic repairs, such as computers and appliances, where precision is crucial.
- Handy for DIY projects that require frequent tool changes, offering versatility in one compact set.
- Great for on-the-go repairs, easily fits in a car trunk or a backpack for quick access.
- Suitable for hobbyists working on models, crafts, or other detailed work requiring multiple tool types.
Combination tool mounting
The magnetic direct mounting is suitable for 3/8" sockets as well as ¼" bits without the need for an adapter.
With integrated bit magazine
A captive, freely swivelling bit magazine for 12 bits (1/4", 25 mm length) is integrated in the handle of the compact Zyklop ratchet.
Swiveling bit magazine
The swiveling bit magazine allows for the bits to be removed easily in almost any situation and cannot be lost. The bits are safely stored.
Freely pivoting ratchet head
The ratchet head pivots freely and can be locked into any defined position by using the slide switch that is positioned on either side. It is even possible to work in very confined and difficult-to-access areas with enhanced hand clearance. The predefined locking at 0°, 15° and 90°, both to the right and left, ensure safe working without any slipping of the ratchet head.
Locking the ratchet head
Thanks to the sliding switch on both sides, the ratchet head can be locked at the pre-defined positions 0° as well as 15° and 90° to the right and left.
Small return angle
The fine toothing with 72 teeth allows for a low return angle of only 5° for working in constricted screwdriving situations.
Simple direction change
The Zyklop Pocket ratchet can be quickly and easily reversed for clockwise/anti-clockwise rotation in any position using the knurl.
