Compact Magnetic Base Drill up to 1-3/8 in [36 mm]
Small and lightweight compact magnetic base drill with forward/reverse operation, designed for access in hard-to-reach areas and easy overhead or vertical work. Built for versatile drilling, tapping, and countersinking applications, this compact mag drill delivers strong performance in tight spaces and demanding jobsite conditions.
Details
This compact magnetic base drill features a powerful, maintenance-free 10 A [1,200 W] HighPerformance brushless motor for reliable drilling performance. Variable speed and forward/reverse operation allow the tool to handle a wide range of drilling applications with precision and control.
The ratcheting handle makes it easier to work in tight spaces, while the German-engineered design provides durability and wear resistance for tough applications. A tilt sensor safety shutoff helps improve workplace safety by shutting down the drill if it moves or breaks free from the workpiece.
Intuitive operator controls are located on top of the drill motor for maximum visibility. The high gear level provides a clear view of the hole location, while the large installation space below the drill spindle and 1-13/16 in [46 mm] stroke support flexible operation. Additional features include an integrated handle, memory function speed storage, onboard 5 mm Allen key storage, inner cooling lubrication with included hand pump, and compatibility with the L-BOXX system.
Technical Data
Power consumption: 1,200 W
Power output: 680 W
Cutter holder: 3/4" straight shank
Full load speed: 130 - 610 rpm
No load speed: 130 - 660 rpm
Carbide cutter max. diameter: 1-3/8 in [35 mm]
HSS cutter max. diameter: 1-3/8 in [35 mm]
Cutter max. drilling depth: 1-3/8 in [35 mm]
Twist drill max. diameter: 9/16 in [14 mm]
Tapping: 3/8" / M10
Max. countersinking diameter: 1-1/4 in [32 mm]
Stroke: 1-13/16 in [46 mm]
Construction height: 6-5/8 in [169 mm]
Length: 11-7/16 in [290 mm]
Magnetic holding force: 2248 lbs [10,000 N]
Cable with plug: 9.8 ft [3 m]
Weight: 18.74 lbs [8.50 kg]
Vibration and Sound Emission Values
Sound pressure level LpA: 91.5 dB
Measurement uncertainty KpA: 5 dB
Sound power level LWA: 104.5 dB
Measurement uncertainty KWA: 5 dB
Peak sound value LpCpeak: 101.8 dB
Measurement uncertainty KpCpeak: 5 dB
Vibration value 1 αhv 3-way: ah,D = <2.5 m/s²
Measurement uncertainty Kα: 1.5 m/s²
Applications
Mag base drilling in metal up to 1-1/2" diameter: Well suitable
Tapping: Well suitable
Countersinking: Well suitable
Performing overhead work: Well suitable
Installation work: Well suitable
Workshop jobs: Well suitable
Product Features
Magnet holding force display
Forward/reverse operation
Electronic speed setting
Memory function
Speed-controlled tacho electronics
Tilt sensor
Uses
- Drilling in hard-to-reach areas
- Overhead drilling
- Vertical drilling
- Compact jobsite drilling
- Magnetic base drilling in metal
- Core drilling up to 1-3/8 in diameter
- Tapping applications
- Countersinking work
- Installation work
- Workshop jobs
- Metal fabrication
- Steel plate drilling
- Maintenance and repair work
- Drilling in tight spaces
- Field service applications
